User Manual
1. Before Using
A. Charging the Battery of the Camera
The Red Light is on When Charging, the Red Light is Off After Being & Fully Charged. The Charging Time is About 2.5 Hours.
Note: This Product Only Supports Memory Cards in Fat Format. 32GB Memory Card Belongs to Fat Format Can Be Directly Read. For the First Time Using Memory Card Above 32gb, the Camera Will Prompt That Memory Card is Being Formatted. It is Recommended That When Using More Than 32GB Memory Card, There Should Be No Other Data in the Card to Avoid Loss of Data.
B. Lens Rotation Operation:
Camera Lens Can Rotate 180 Degrees to Meet Various Shooting Needs.
2. Photo/ Video/ Lapse Video Operation
A. Long Press the Power Button. The LCD Screen Will Light Up and Blue Light is on, Indicating the Camera is Powered on. The Power-on Interface is as Shown Below. Short Press Power Button to Turn Off the Screen, and Long Press Power Button to Turn It Off.
B. When the Camera is Powered on, Swipe Down to Activate Three Modes: Photo Mode, Video Mode, and Lapse Video Mode. Swipe Up to Return to the Home Page.
C. One Button Video Recording: When the Camera is Powered Off, Long Press the Video Button to Start Video.
Three Mode: Swipe Down to Enter the Menu When Power on. There Are 3 Modes: Video Recording Mode, Photo Mode, and Time-lapse Recording Mode. Swipe Left or Right to Select. Default Video Recording Mode.
3. Swipe up to Enter the Settings
4. Wifi Mode
1. After Turning on Wifi, Scan the QR Code to Download and Install Viidure App.
a. IOS is downloaded from the Apple Store by Searching Viidure.
b. For Foreign Android Systems, Searching Viidure on Google Play to Download.
c. For Chinese Android Systems, Downloading Viidure from the App Store and Install it.
2. The Green Light Flashes When Waiting for Connection. The Green Light is Always on When Connecting Successfully.
3. Enter the Mobile Phone Wifi Setting to Connect the Wifi Name Beginning of "H91wwwww", the Password is "12345678". Click the Camera Icon in the Middle of App and Enter the Actual Operation of the Camera.
4. When Recording Video via the App, Touch the Back Button to Disconnect the Phone From Wi-fi. The Camera Will Then Return to the Home Screen.
5. Video Recording Settings as Following
6. System Setting Menu as Shown Below:
7. Language Mode as Shown Below.
8. Playback Mode,
A. See the Video Below.
1. Swipe Right to Enter Playback Mode and View the Video. Swipe Left to Exit Mode.
2. Swipe Up or Down to Select a Video, Then Tap the Play Icon to Play It.
3. While the Video is Playing, Swipe Up or Down to Increase or Decrease the Volume.
4. Tap the "Delete" Icon to Delete the Video.
B. See the Image Below.
1. Swipe Left to Enter Playback Mode and View Photos. Swipe Right to Exit Mode.
2. Swipe Up or Down to Select Photos.
3. Tap the "Delete" Icon to Delete Photos.
9. Connecting Computer:
Use the Included Type-C Cable to Connect Computer. The Camera Will Automatically Power on, and the Screen Will Display Two Options: as Shown Below:
1) Storage Mode
Select [Storage Mode] You Can Play the Video Files on the Memory Card, Allowing You to Transfer Files From the Memory Card to Your Computer.
2) Camera Mode
Select [Camera] to Use the Camera as a Webcam. While It is Used as Webcam, Other Functions Are Unavailable.
10. Charging Pod
The Charging Pod Has 4 Lights. One Blue Light Represents 25% Power. When All 4 Blue Lights Are on, the Charging Pod is Fully Charged.
1. Power ON: Short Press the Power Button Once to Turn It on.
2. Charging Indicator: Blue Light Flashes Indicates It is Charging, and Blue Light is Always on When Fully Charged. a Full Charge Takes Approximately 3 Hours With Using a 2A Charger.
3. Power OFF: Press the Power Button Twice Continuously to Turn the Charging Pod Off.
11. If You Encounter Camera Problems, Please Refer to This Section.
1. The Camera Cannot Be Turned on.
A. The Battery is Low. Please Charge It Immediately.
B. Press the Reset Button to Reset the Device and Then Restart It.
2. The Camera Does Not Charge
The Charging Indicator Light is Off, Which Means the Charger is Not Properly Connected. Please Check Whether the Charger is Properly Connected.
3. The Memory Card Cannot Be Recognized
A. Please Check Whether the Memory Card is Memory Card (Class 10) and the Maximum Capacity is Not More Than 256G.
B. Please Check Whether the Memory Card is Inserted Upside Down.
C. When Using a Memory Card on a Camera for the First Time, It is Recommended to Format It First.
4. Additional Notes
A. Do Not Insert Any Objects Other Than the Memory Card Into the Slot.
B. It is Normal for the Memory Card to Heat Up After Long Time Use.
C. It is Normal for the Camera Screen to Heat Up After Long Time Use.
This Device Complies With Part 15 of the FCC Rules. Operation is Subject to the Following Two Conditions:
(1) This Device May Not Cause Harmful Interference, and
(2) This Device Must Accept Any Interference Received, Including Interference That May Cause Undesired Operation.
